Foundations of Security Week2 Lecture

Whole number#

• A whole number is any non-negative integer without a decimal component.
• This includes all numbers from 0 upwards: 0, 1, 2, 3, 4, 5, …….etc.
• Whole numbers are essentially the set of natural numbers including zero.

Natural number#

• A natural number is any integer greater than zero.
• These are members of the set {1, 2, 3, 4, …}.
• Natural numbers are also known as counting numbers.

What is a Factor?#

• A factor is a number that divides another number completely without leaving a remainder.
• Factors are numbers you multiply together to produce another number.
• Example 1: 4 is a factor of 8 because 8 ÷ 4 = 2 and the remainder is 0.
• Example 2: For 8, the factors include 1, 2, 4, and 8:
  • 8 = 1 × 8
  • 8 = 2 × 4
  • 8 = 4 × 2
  • 8 = 8 × 1

What is a Prime Number?#

• A prime number is defined as a number greater than 1 that has no divisors/factors other than 1 and itself.
• A number that can be factored only as 1 times itself is called “prime.“
• 1 is not a prime number because it does not have two distinct factors.
• Examples:
  • Example 1: 3 is a prime number because it is greater than 1 and its only factors are 1 and 3 (3 = 1 × 3).
  • Example 2: 23 is a prime number because its only factors are 1 and 23 (23 = 1 × 23).

What is a Composite Number?#

• A composite number is a positive integer that has more than two factors.
• This means it can be divided evenly by numbers other than 1 and itself.
• Examples of composite numbers include: 4, 6, 9, 10, 12, 14, 15, 16, etc.
• Example:
  • 15 is a composite number because it can be factored as:
    • 15 = 1 × 15
    • 15 = 3 × 5
    • Thus, the factors of 15 are 1, 3, 5, and 15 itself, exceeding two distinct factors.

What is the Greatest Common Divisor (GCD)?#

• The GCD of two or more integers, none of which are zero, is the largest positive integer that divides each of the numbers without any remainder.
• Consider two numbers 𝑎 and 𝑏. The GCD of these numbers is the highest number that divides both 𝑎 and 𝑏 evenly.
• Example:
  • GCD of 12 and 8:
    • 1 divides both 12 and 8 (12 ÷ 1 = 12, 8 ÷ 1 = 8)
    • 2 divides both 12 and 8 (12 ÷ 2 = 6, 8 ÷ 2 = 4)
    • 4 divides both 12 and 8 (12 ÷ 4 = 3, 8 ÷ 4 = 2)
  • Thus, the GCD of 12 and 8 is 4, as it is the greatest integer that divides both without leaving a remainder.

How to find GCD#

• There are numerous ways to find GCD of two numbers. These include:
  1. Listing method
  2. Prime factorization method
  3. Long division method
  4. Repeated division method
  5. Euclid’s division algorithm

What is a Co-Prime Number?#

• Co-prime numbers are two or more numbers whose greatest common divisor (GCD) is 1.
• For example, 7 and 8 are co-prime numbers because their GCD is 1.

Properties of Co-Prime Numbers:

• 1 is co-prime with every other number.
• Prime numbers are co-prime with each other.
• Any two successive numbers (consecutive integers) are always co-prime.
• The sum of any two co-prime numbers is always co-prime with their product.

Example 1:

• 1 and 8: The GCD of 1 and 8 is 1.
• 1 and 98774747: The GCD of 1 and 98774747 is also 1, demonstrating that 1 is co-prime with any other number.

Example 2:

• Prime numbers are naturally co-prime to each other. For instance, 3 and 5 are both prime numbers, and their GCD is 1. Thus, they are co-prime.

Example 3:

• Any two successive numbers are co-prime. For example, the GCD of 18 and 19 is 1, making them co-prime. Similarly, 19 and 20 are also co-prime as their GCD is 1.

Example 4:

• A key property of co-prime numbers is that the sum of any two co-prime numbers is also co-prime with their product. For instance, consider the numbers 19 and 20:
  • The sum of 19 and 20 is 39.
  • The product of 19 and 20 is 380.
  • The GCD of 39 and 380 is 1, confirming that 19 and 20 are co-prime.

Quiz: Find the Set of Co-Prime Numbers#

• Determine if each pair of numbers is co-prime (i.e., their greatest common divisor is 1):
  A.24, 36
  B.20, 21
  C.542, 446
  D.765, 345

Division Algorithm#

• For any positive integer 𝑛 and any non-negative integer 𝑎, when 𝑎 is divided by 𝑛, it results in an integer quotient 𝑞 and an integer remainder 𝑟 that satisfy the equation:

Example:

• Consider dividing 864 by 45:
  • 864 ÷ 45 = 19 remainder 9
  • Therefore, 864 = 45×19 + 9
  • This confirms that 𝑎 = 𝑞𝑛 + 𝑟

Find the Set of Co-Prime Numbers#

Proof of Linear Combination Property:

• When we say 𝑏∣𝑔, it implies 𝑔 = 𝑏 × 𝑘 (this is the property of a divisor). Similarly, if 𝑏∣ℎ, it implies ℎ = 𝑏 × 𝑘′ .
• Therefore, for any integers 𝑚 and 𝑛:
  • 𝑚𝑔+𝑛ℎ = 𝑚𝑏𝑘 + 𝑛𝑏𝑘′ = 𝑏(𝑚𝑘+𝑛𝑘′) = 𝑏𝑀,
• where 𝑀 is an integer given by 𝑀= 𝑚𝑘 + 𝑛𝑘′.

Example of Property 4:

• Let 𝑏=7, 𝑔=14, and ℎ=63; choose 𝑚=3 and 𝑛=2.
• To verify:
  • 3𝑔 + 2ℎ = 3×14 + 2×63 = 42 + 126 =168
    • 168 =7 × 24  ⟹  7∣168 Thus, it is evident that 7∣(3×14 + 2×63).

Quiz Modular Arithmetic#

Find the result of the following modulo arithmetic operations:

• 18 mod 12 = 6
• 24 mod 12 = 0
• 32 mod 12 = 8
• 4 mod 12 = 4
• 8 mod 12 = 8

Congruence#

• Using this 12-hour clock as an example, if I say, “I want to meet you at 16,” this means I want to meet with you at 4 o’clock.
• This can be represented as 16 ≡ 4(mod12).
• This means when you divide 16 by 12, the remainder is 4, thus indicating the time on a 12-hour clock.

Properties of Congruence#

Congruence in modular arithmetic is a relationship between integers indicating that they leave the same remainder when divided by a modulus 𝑛. If 𝑎 and 𝑏 are integers and 𝑛>0, 𝑎 ≡ 𝑏 mod 𝑛 means 𝑛 divides (𝑎−𝑏) without a remainder.

Example 1:

16 ≡ 4 mod 12 indicates that 12 divides 16−4=12 evenly.

Reflexivity Property:

𝑎 ≡ 𝑎 mod 𝑛 for any integer 𝑎. This is because the difference 𝑎−𝑎=0, and any number divides zero.

Example 2:

Consider 𝑎=15 and 𝑛=12, thus 15 ≡ 3 mod 12 since the remainder when 15 is divided by 12 is 3.

Symmetry Property:

If 𝑎 ≡ 𝑏 mod 𝑛, then 𝑏 ≡ 𝑎 mod 𝑛. This follows because if 𝑛 divides (𝑎−𝑏), it also divides (𝑏−𝑎)(as 𝑏−𝑎=−(𝑎−𝑏)).

Example of Symmetry:

Since 20 ≡ 30 mod 10, it follows that 30 ≡ 20 mod 10, demonstrating that the difference of 20 and 30 (i.e., −10) is also divisible by 10.

Transitivity Property:

If 𝑎 ≡ 𝑏 mod 𝑛 and 𝑏 ≡ 𝑐 mod 𝑛, then 𝑎 ≡ 𝑐 mod 𝑛. This property ensures that congruence relations can form equivalence classes under modulo operations.

Proof for Symmetry:

Given 𝑛∣(𝑎−𝑏) and 𝑛∣(𝑏−𝑎), it follows that 𝑛∣((𝑎−𝑏) + (𝑏−𝑎)) = 𝑛∣0, confirming the symmetry as proved.

Modular arithmetic Properties#

• Property[1]: $\color{blue} (a + b) \bmod n = [(a \bmod n) + (b \bmod n)] \bmod n$

Example: For example, a = 30, b = 12, and n = 5

• $\color{blue} (a − b)\bmod n = [(a \bmod n) − (b \bmod n)]\bmod n$
• $\color{blue} (a ~ × ~ b)\bmod n = [(a \bmod n) ~ × ~ (b \bmod n)]\bmod n$

Example: For example, a = 30, b = 12, and n = 5

Modular Exponentiation#

How to Compute:

• Compute $𝑐 = 𝑎^𝑚 \bmod\,𝑛$

Example: $𝑐 =𝑎^{10} \bmod\,5$

• Key Properties:
  • Multiplicative property: $(𝑥^𝑎)^𝑏=𝑥^{𝑎𝑏}$
  • Distributive property over addition: $𝑥^{𝑎+𝑏} = 𝑥^𝑎 × 𝑥^𝑏$

How to Compute:

• Step by Step Solution for $3^{10} \bmod\,5$:
• Calculate $3^2 \bmod\,5$:
  • $3^2 = 9$
  • $9 \bmod\,5 = 4$
• Calculate $3^4 \bmod\,5$ using the square of the result:
  • $(3^2 \bmod\,5)^2 = 4^2=16$
  • $16 \bmod\,5=1$
• Calculate $3^8 \bmod\,5$ using the square of $3^4 \bmod\,5$:
  • $(3^4 \bmod\,5)^2 = 1^2 = 1$
• Finally, calculate $3^{10} \bmod\,5$:
  • $3^{10} =(3^8×3^2) \bmod\,5$
  • $(1×4) mod\,5 = 4$
• Conclusion: $3^{10} \bmod\,5 = 4$

Quiz Modular Exponentiation#

Compute:

• Compute $2^{34} \bmod 3$
• Compute $3^{30} \bmod 5$
